Parsing A Boolean Expression

1106. Parsing A Boolean Expression

Difficulty: Hard

Topics: String, Stack, Recursion

A boolean expression is an expression that evaluates to either true or false. It can be in one of the following shapes:

• 't' that evaluates to true.
• 'f' that evaluates to false.
• '!(subExpr)' that evaluates to the logical NOT of the inner expression subExpr.
• '&(subExpr₁, subExpr₂, ..., subExpr_n)' that evaluates to the logical AND of the inner expressions subExpr₁, subExpr₂, ..., subExpr_n where n >= 1.
• '|(subExpr₁, subExpr₂, ..., subExpr_n)' that evaluates to the logical OR of the inner expressions subExpr₁, subExpr₂, ..., subExpr_n where n >= 1.

Given a string expression that represents a boolean expression, return the evaluation of that expression.

It is guaranteed that the given expression is valid and follows the given rules.

Example 1:

• Input: expression = "&(|(f))"
• Output: false
• Explanation:
  • First, evaluate |(f) --> f. The expression is now "&(f)".
  • Then, evaluate &(f) --> f. The expression is now "f".
  • Finally, return false.

Example 2:

• Input: expression = "|(f,f,f,t)"
• Output: true
• Explanation: The evaluation of (false OR false OR false OR true) is true.

Example 3:

• Input: expression = "!(&(f,t))"
• Output: true
• Explanation:
  • First, evaluate &(f,t) --> (false AND true) --> false --> f. The expression is now "!(f)".
  • Then, evaluate !(f) --> NOT false --> true. We return true.

Constraints:

• 1 <= expression.length <= 2 * 10⁴
• expression[i] is one following characters: '(', ')', '&', '|', '!', 't', 'f', and ','.

Hint:

1. Write a function "parse" which calls helper functions "parse_or", "parse_and", "parse_not".

Solution:

We will break down the solution into smaller functions that handle parsing and evaluating different types of expressions: parse_or, parse_and, parse_not, and a main parse function that handles the parsing of the expression recursively. We will use a stack to keep track of nested expressions and evaluate them step-by-step.

Approach:

1. Parsing and Recursion:

   • Use a stack to keep track of expressions when encountering nested parentheses.
   • Process characters sequentially and manage the stack for nested evaluations.
   • When encountering a closing parenthesis ), extract the last set of expressions and apply the logical operation (&, |, or !).

2. Helper Functions:

   • parse_or: Evaluates |(expr1, expr2, ..., exprN) by returning true if at least one sub-expression is true.
   • parse_and: Evaluates &(expr1, expr2, ..., exprN) by returning true only if all sub-expressions are true.
   • parse_not: Evaluates !(expr) by returning the opposite of the sub-expression.

3. Expression Handling:

   • Single characters like t and f directly translate to true and false.
   • When an operation is encountered (&, |, !), the inner expressions are evaluated based on their respective rules.

Let's implement this solution in PHP: 1106. Parsing A Boolean Expression



  Explanation:




Main Function (parseBooleanExpression):


Iterates through the expression and pushes characters to a stack.
When encountering a ), it collects all the elements inside the parentheses and evaluates them based on the operation (&, |, !).
Converts results to 't' (true) or 'f' (false) and pushes them back to the stack.







Helper Functions:



parse_and: Returns true if all sub-expressions are 't' (true).

parse_or: Returns true if any sub-expression is 't'.

parse_not: Reverses the boolean value of a single sub-expression.










  Example Walkthrough:




Input: "&(|(f))"


Stack processing:



&, (, |, (, f, ), ) → The inner expression |(f) is evaluated to f.
Resulting in &(f), which evaluates to f.


Output: false.



Input: "|(f,f,f,t)"


Evaluates the | operation:


Finds one 't', thus evaluates to true.


Output: true.



Input: "!(&(f,t))"

Stack processing:



!, (, &, (, f, ,, t, ), ) → &(f,t) evaluates to f.

!(f) is then evaluated to true.


Output: true.







  Complexity:




Time Complexity: O(N), where N is the length of the expression. Each character is processed a limited number of times.

Space Complexity: O(N), due to the stack used to keep track of nested expressions.


This solution is well-suited for the constraints and should handle the input size effectively.
