Why does adding and focusing on a JTextField over a double-buffered animated JPanel in Swing cause flickering issues on Mac OS X 10.5 with Java 1.6?

JTextFields on top of active drawing on JPanel, threading problems

Swing can be used to create a proper multi-buffered rendering environment on top of which Swing user interface elements can be added. In this case, we have an animating red rectangle drawn onto a background. The background does not need to be updated every frame, so we render it onto a BufferedImage and redraw only the portion necessary to clear the previous location of the rectangle.

So far so good; smooth animation, low cpu usage, no flickering. Then we add a JTextField to the Jpanel (by clicking on any position on the screen), and focus on it by clicking inside the text box. Clearing the previous location of the rectangle now fails on every cursor blink, see the image below.

We are curious if anyone has an idea of why this might happen (Swing not being thread-safe? The image being painted asynchronously?) and in what direction to look for possible solutions.

This is on Mac OS 10.5, Java 1.6.

NewTest extends JPanel; but because you're not painting every pixel on each call to paintComponent(), you need to invoke the super-class's method and erase the old drawing:

@Override
protected void paintComponent(Graphics g) {
    super.paintComponent(g);
    int width = this.getWidth();
    int height = this.getHeight();
    g.setColor(Color.black);
    g.fillRect(0, 0, width, height);
    ...
}

Addendum: As you note, setting the background color in the constructor precludes the need to fill the panel in paintComponent(), while super.paintComponent() allows the text field(s) to function correctly. As you observe, the proposed workaround is fragile. Instead, simplify the code and optimize as warranted. For example, you may not need the complication of insets, extra buffers and a component listener.

Addendum 2: Note that super.paintComponent() calls the UI delegate's update() method, "which fills the specified component with its background color (if its opaque property is true)." You can use setOpaque(false) to preclude this.

A further improved version of the code, with some additional features and optimizations:

import java.awt.Color;
import java.awt.Dimension;
import java.awt.EventQueue;
import java.awt.Graphics;
import java.awt.Graphics2D;
import java.awt.GraphicsConfiguration;
import java.awt.GraphicsEnvironment;
import java.awt.Rectangle;
import java.awt.Transparency;
import java.awt.event.ActionEvent;
import java.awt.event.ActionListener;
import java.awt.event.ComponentAdapter;
import java.awt.event.ComponentEvent;
import java.awt.event.MouseAdapter;
import java.awt.event.MouseEvent;
import java.awt.image.BufferedImage;
import java.util.Random;
import javax.swing.JFrame;
import javax.swing.JPanel;
import javax.swing.JTextField;
import javax.swing.Timer;

/** @see http://stackoverflow.com/questions/3256941 */
public class AnimationTest extends JPanel implements ActionListener {

    private static final int WIDE = 640;
    private static final int HIGH = 480;
    private static final int RADIUS = 25;
    private static final int FRAMES = 24;
    private final Timer timer = new Timer(20, this);
    private final Rectangle rect = new Rectangle();
    private BufferedImage background;
    private int index;
    private long totalTime;
    private long averageTime;
    private int frameCount;

    public static void main(String[] args) {
        EventQueue.invokeLater(new Runnable() {

            @Override
            public void run() {
                new AnimationTest().create();
            }
        });
    }

    private void create() {
        JFrame f = new JFrame("AnimationTest");
        f.setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE);
        f.add(this);
        f.pack();
        f.setLocationRelativeTo(null);
        f.setVisible(true);
        timer.start();
    }

    public AnimationTest() {
        super(true);
        this.setOpaque(false);
        this.setPreferredSize(new Dimension(WIDE, HIGH));
        this.addMouseListener(new MouseHandler());
        this.addComponentListener(new ComponentHandler());
    }

    @Override
    protected void paintComponent(Graphics g) {
        long start = System.nanoTime();
        super.paintComponent(g);
        int w = this.getWidth();
        int h = this.getHeight();
        g.drawImage(background, 0, 0, this);
        double theta = 2 * Math.PI * index++ / 64;
        g.setColor(Color.blue);
        rect.setRect(
            (int) (Math.sin(theta) * w / 3 + w / 2 - RADIUS),
            (int) (Math.cos(theta) * h / 3 + h / 2 - RADIUS),
            2 * RADIUS, 2 * RADIUS);
        g.fillOval(rect.x, rect.y, rect.width, rect.height);
        g.setColor(Color.white);
        if (frameCount == FRAMES) {
            averageTime = totalTime / FRAMES;
            totalTime = 0; frameCount = 0;
        } else {
            totalTime += System.nanoTime() - start;
            frameCount++;
        }
        String s = String.format("%1.3f", averageTime / 1000000d);
        g.drawString(s, 5, 16);
    }

    @Override
    public void actionPerformed(ActionEvent e) {
        this.repaint();
    }

    private class MouseHandler extends MouseAdapter {

        @Override
        public void mousePressed(MouseEvent e) {
            super.mousePressed(e);
            JTextField field = new JTextField("test");
            Dimension d = field.getPreferredSize();
            field.setBounds(e.getX(), e.getY(), d.width, d.height);
            add(field);
        }
    }

    private class ComponentHandler extends ComponentAdapter {

        private final GraphicsEnvironment ge =
            GraphicsEnvironment.getLocalGraphicsEnvironment();
        private final GraphicsConfiguration gc =
            ge.getDefaultScreenDevice().getDefaultConfiguration();
        private final Random r = new Random();

        @Override
        public void componentResized(ComponentEvent e) {
            super.componentResized(e);
            int w = getWidth();
            int h = getHeight();
            background = gc.createCompatibleImage(w, h, Transparency.OPAQUE);
            Graphics2D g = background.createGraphics();
            g.clearRect(0, 0, w, h);
            g.setColor(Color.green.darker());
            for (int i = 0; i < 128; i++) {
                g.drawLine(w / 2, h / 2, r.nextInt(w), r.nextInt(h));
            }
            g.dispose();
            System.out.println("Resized to " + w + " x " + h);
        }
    }
}
