How can I identify and polygonize convex holes within a 2D point cloud using C#?

Jan 18, 2025 am 07:22 AM

How can I identify and polygonize convex holes within a 2D point cloud using C#?

This code demonstrates an approach to finding convex holes in a set of 2d points. The approach involves creating a bitmap of the point cloud, computing the data density for each cell in the bitmap, creating a list of unused areas (map[][] = 0 or map[][] <= treshold), segmenting the list of unused areas into groups of connected components, and polygonizing each group of connected components to obtain the convex polygons representing the holes.

Here's the C# implementation of the algorithm provided:

1

2

3

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19

20

21

22

23

24

25

26

27

28

29

30

31

32

33

34

35

36

37

38

39

40

41

42

43

44

45

46

47

48

49

50

51

52

53

54

55

56

57

58

59

60

61

62

63

64

65

66

67

68

69

70

71

72

73

74

75

76

77

78

79

80

81

82

83

84

85

86

87

88

89

90

91

92

93

94

95

96

97

98

99

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

using System;

using System.Collections.Generic;

using System.Linq;

using System.Drawing;



namespace HoleFinder

{

    class Program

    {

        // Define a cell structure for the bitmap

        public struct Cell

        {

            public double x0, x1, y0, y1; // Bounding box of points inside the cell

            public int count;            // Number of points inside the cell

        }



        // Define a line structure for representing hole boundaries

        public struct Line

        {

            public double x0, y0, x1, y1; // Line edge points

            public int id;             // Id of the hole to which the line belongs for segmentation/polygonization

            public int i0, i1, j0, j1;    // Index in map[][]

        }



        // Compute the bounding box of the point cloud

        public static (double x0, double x1, double y0, double y1) ComputeBoundingBox(List<point> points)

        {

            double x0 = points[0].X;

            double x1 = points[0].X;

            double y0 = points[0].Y;

            double y1 = points[0].Y;



            foreach (var point in points)

            {

                if (point.X < x0) x0 = point.X;

                if (point.X > x1) x1 = point.X;

                if (point.Y < y0) y0 = point.Y;

                if (point.Y > y1) y1 = point.Y;

            }



            return (x0, x1, y0, y1);

        }



        // Create a bitmap of the point cloud

        public static int[,] CreateBitmap(List<point> points, (double x0, double x1, double y0, double y1) boundingBox, int N)

        {

            // Create a 2D array to represent the bitmap

            int[,] bitmap = new int[N, N];



            // Compute the scale factors for converting point coordinates to bitmap indices

            double mx = N / (boundingBox.x1 - boundingBox.x0);

            double my = N / (boundingBox.y1 - boundingBox.y0);



            // Iterate over the points and increment the corresponding cells in the bitmap

            foreach (var point in points)

            {

                int i = (int)Math.Round((point.X - boundingBox.x0) * mx);

                int j = (int)Math.Round((point.Y - boundingBox.y0) * my);



                if (i >= 0 && i < N && j >= 0 && j < N)

                    bitmap[i, j]++;

            }



            return bitmap;

        }



        // Compute the data density for each cell in the bitmap

        public static void ComputeDataDensity(int[,] bitmap, Cell[] map)

        {

            for (int i = 0; i < map.Length; i++)

            {

                map[i].count = 0;

            }



            for (int i = 0; i < bitmap.GetLength(0); i++)

            {

                for (int j = 0; j < bitmap.GetLength(1); j++)

                {

                    map[i * bitmap.GetLength(1) + j].count += bitmap[i, j];

                }

            }

        }



        // Create a list of unused areas (map[][] = 0 or map[][] <= treshold)

        public static List<(int i0, int i1, int j0, int j1)> FindUnusedAreasHorizontalVertical(Cell[] map, int N, int treshold = 0)

        {

            List<(int i0, int i1, int j0, int j1)> unusedAreas = new List<(int, int, int, int)>();



            // Scan horizontally

            for (int j = 0; j < N; j++)

            {

                int i0 = -1;

                int i1 = -1;

                for (int i = 0; i < N; i++)

                {

                    if (map[i * N + j].count == 0 || map[i * N + j].count <= treshold)

                    {

                        if (i0 < 0) i0 = i;

                    }

                    else

                    {

                        if (i0 >= 0)

                        {

                            unusedAreas.Add((i0, i1, j, j));

                            i0 = -1;

                            i1 = -1;

                        }

                    }

                }



                if (i0 >= 0) unusedAreas.Add((i0, i1, j, j));

            }



            // Scan vertically

            for (int i = 0; i < N; i++)

            {

                int j0 = -1;

                int j1 = -1;

                for (int j = 0; j < N; j++)

                {

                    if (map[i * N + j].count == 0 || map[i * N + j].count <= treshold)

                    {

                        if (j0 < 0) j0 = j;

                    }

                    else

                    {

                        if (j0 >= 0)

                        {

                            unusedAreas.Add((i, i, j0, j1));

                            j0 = -1;

                            j1 = -1;

                        }

                    }

                }



                if (j0 >= 0) unusedAreas.Add((i, i, j0, j1));

            }



            return unusedAreas;

        }



        // Segment the list of unused areas into groups of connected components

        public static List<list<(int i0,="" int="" i1,="" j0,="" j1)="">> SegmentUnusedAreas(List<(int i0, int i1, int j0, int j1)> unusedAreas)

        {

            // Initialize each unused area as a separate group

            List<list<(int i0,="" int="" i1,="" j0,="" j1)="">> segments = new List<list<(int i0,="" int="" i1,="" j0,="" j1)="">>();

            foreach (var unusedArea in unusedAreas)

            {

                segments.Add(new List<(int i0, int i1, int j0, int j1)> { unusedArea });

            }



            // Iterate until no more segments can be joined

            bool joined = true;

            while (joined)

            {

                joined = false;



                // Check if any two segments intersect or are adjacent

                for (int i = 0; i < segments.Count; i++)

                {

                    for (int j = i + 1; j < segments.Count; j++)

                    {

                        // Check for intersection

                        bool intersects = false;

                        foreach (var unusedArea1 in segments[i])

                        {

                            foreach (var unusedArea2 in segments[j])

                            {

                                if (unusedArea1.i0 <= unusedArea2.i1 && unusedArea1.i1 >= unusedArea2.i0

                                    && unusedArea1.j0 <= unusedArea2.j1 && unusedArea1.j1 >= unusedArea2.j0)

                                {

                                    intersects = true;

                                    break;

                                }

                            }



                            if (intersects) break;

                        }



                        // Check for adjacency

                        bool adjacent = false;

                        if (!intersects)

                        {

                            foreach (var unusedArea1 in segments[i])

                            {

                                foreach (var unusedArea2 in segments[j])

                                {

                                    if (unusedArea1.i0 == unusedArea2.i0 && unusedArea1.i1 == unusedArea2.i1

                                        && ((unusedArea1.j1 == unusedArea2.j0 && Math.Abs(unusedArea1.j0 - unusedArea2.j1) == 1)

                                            || (unusedArea1.j0 == unusedArea2.j1 && Math.Abs(unusedArea1.j1 - unusedArea2.j0) == 1)))

                                    {

                                        adjacent = true;

                                        break;

                                    }



                                    if (unusedArea1.j0 == unusedArea2.j0 && unusedArea1.j1 == unusedArea2.j1<p></p><p>The above is the detailed content of How can I identify and polygonize convex holes within a 2D point cloud using C#?. For more information, please follow other related articles on the PHP Chinese website!</p>





                        </list<(int></list<(int></list<(int></point></point>
