Simple version of TimSort sorting algorithm

1. Principle and implementation of the simple version of TimSort sorting algorithm

TimSort sorting algorithm is the default sorting algorithm for object arrays in Python and Java. The essence of the TimSort sorting algorithm is a merge sort algorithm, but a lot of optimizations have been made on the merge sort algorithm. The data we need to sort in daily life is usually not completely random, but partially ordered or partially reversed, so TimSort makes full use of the ordered parts for merge sorting. Now we provide a simple version of the TimSort sorting algorithm, which mainly makes the following optimizations:

1.1 Utilize the originally ordered fragments

First define a minimum merge length. Check the originally ordered fragments in the array. If the ordered length is less than the specified minimum merge length, then expand the ordered fragments through insertion sort (the reason for this is to avoid merging fragments with smaller lengths, because this The efficiency is relatively low). Push the starting index position and ordered length of the ordered fragment onto the stack.

1.2 Avoid merging a longer ordered fragment with a smaller ordered fragment, because this is less efficient:

(1) If there are at least three ordered sequences in the stack, we use X , Y, Z respectively represent the three existing sequence fragments from the top of the stack downward, and are merged when the lengths of the three satisfy X+Y>=Z.

(1.1) If 1.2) Otherwise, pop X and Y off the stack, and push the merged result onto the stack. Note that in fact we will not actually pop the stack. There are some techniques in writing code that can achieve the same effect and be more efficient.

(2) If the condition of X+Y>=Z is not met or there are only two sequences in the stack, we use X and Y to represent the lengths of the two existing sequences from the top of the stack downwards. If Y performs the merge, and then pushes the merged ordered fragment results onto the stack.

1.3 When merging two ordered fragments, the so-called gallop mode is used, which can reduce the length of data involved in the merge

Assume that the two ordered fragments that need to be merged are X and Y respectively. , if the first m elements of the X segment are smaller than the first element of the Y segment, then these m elements do not actually need to participate in the merge, because the m elements are still at their original positions after the merge. In the same way, if the last n elements of the Y fragment are larger than the last element of X, then the last n elements of Y do not need to participate in the merge. This reduces the length of the merged array (the simple version does not do this), and also reduces the length of data copied back and forth between the array to be sorted and the auxiliary array, thereby improving the efficiency of the merge.

2. Java source code

package datastruct;

import java.lang.reflect.Array;
import java.util.Arrays;
import java.util.Random;
import java.util.Scanner;

public class SimpleTimSort<T extends Comparable<? super T>>{
    //最小归并长度
    private static final int MIN_MERGE = 16;
    //待排序数组
    private final T[] a;
    //辅助数组
    private T[] aux;
    //用两个数组表示栈
    private int[] runsBase = new int[40];
    private int[] runsLen = new int[40];
    //表示栈顶指针
    private int stackTop = 0;

    @SuppressWarnings("unchecked")
    public SimpleTimSort(T[] a){
        this.a = a;
        aux = (T[]) Array.newInstance(a[0].getClass(), a.length);
    }

    //T[from, to]已有序，T[to]以后的n元素插入到有序的序列中
    private void insertSort(T[] a, int from, int to, int n){
        int i = to + 1;
        while(n > 0){
            T tmp = a[i];
            int j;
            for(j = i-1; j >= from && tmp.compareTo(a[j]) < 0; j--){
                a[j+1] = a[j];
            }
            a[++j] = tmp;
            i++;
            n--;
        }
    }

    //返回从a[from]开始，的最长有序片段的个数
    private int maxAscendingLen(T[] a, int from){
        int n = 1;
        int i = from;

        if(i >= a.length){//超出范围
            return 0;
        }

        if(i == a.length-1){//只有一个元素
            return 1;
        }

        //至少两个元素
        if(a[i].compareTo(a[i+1]) < 0){//升序片段
            while(i+1 <= a.length-1 && a[i].compareTo(a[i+1]) <= 0){
                i++;
                n++;
            }
            return n;
        }else{//降序片段，这里是严格的降序，不能有>=的情况，否则不能保证稳定性
            while(i+1 <= a.length-1 && a[i].compareTo(a[i+1]) > 0){
                i++;
                n++;
            }
            //对降序片段逆序
            int j = from;
            while(j < i){
                T tmp = a[i];
                a[i] = a[j];
                a[j] = tmp;
                j++;
                i--;
            }
            return n;
        }
    }

    //对有序片段的起始索引位置和长度入栈
    private void pushRun(int base, int len){
        runsBase[stackTop] = base;
        runsLen[stackTop] = len;
        stackTop++;
    }

    //返回-1表示不需要归并栈中的有序片段
    public int needMerge(){
        if(stackTop > 1){//至少两个run序列
            int x = stackTop - 2;
            //x > 0 表示至少三个run序列
            if(x > 0 && runsLen[x-1] <= runsLen[x] + runsLen[x+1]){
                if(runsLen[x-1] < runsLen[x+1]){
                    //说明 runsLen[x+1]是runsLen[x]和runsLen[x-1]中最大的值
                    //应该先合并runsLen[x]和runsLen[x-1]这两段run
                    return --x;
                }else{
                    return x;
                }
            }else
            if(runsLen[x] <= runsLen[x+1]){
                return x;
            }else{
                return -1;
            }
        }
        return -1;
    }

    //返回后一个片段的首元素在前一个片段应该位于的位置
    private int gallopLeft(T[] a, int base, int len, T key){
        int i = base;
        while(i <= base + len - 1){
            if(key.compareTo(a[i]) >= 0){
                i++;
            }else{
                break;
            }
        }
        return i;
    }

    //返回前一个片段的末元素在后一个片段应该位于的位置
    private int gallopRight(T[] a, int base, int len, T key){
        int i = base + len -1;
        while(i >= base){
            if(key.compareTo(a[i]) <= 0){
                i--;
            }else{
                break;
            }
        }
        return i;
    }

    public void mergeAt(int x){
        int base1 = runsBase[x];
        int len1 = runsLen[x];

        int base2 = runsBase[x+1];
        int len2 = runsLen[x+1];

        //合并run[x]和run[x+1],合并后base不用变,长度需要发生变化
        runsLen[x] = len1 + len2;
        if(stackTop == x + 3){
            //栈顶元素下移，省去了合并后的先出栈，再入栈
            runsBase[x+1] = runsBase[x+2];
            runsLen[x+1] = runsLen[x+2];
        }
        stackTop--;

        //飞奔模式，减小归并的长度
        int from = gallopLeft(a, base1, len1, a[base2]);
        if(from == base1+len1){
            return;
        }
        int to = gallopRight(a, base2, len2, a[base1+len1-1]);

        //对两个需要归并的片段长度进行归并
        System.arraycopy(a, from, aux, from, to - from + 1);
        int i = from;
        int iend = base1 + len1 - 1;

        int j = base2;
        int jend = to;

        int k = from;
        int kend = to;

        while(k <= kend){
            if(i > iend){
                a[k] = aux[j++];
            }else
            if(j > jend){
                a[k] = aux[i++];
            }else
            if(aux[i].compareTo(aux[j]) <= 0){//等号保证排序的稳定性
                a[k] = aux[i++];
            }else{
                a[k] = aux[j++];
            }
            k++;
        }
    }

    //强制归并已入栈的序列
    private void forceMerge(){
        while(stackTop > 1){
            mergeAt(stackTop-2);
        }
    }

    //timSort的主方法
    public void timSort(){
        //n表示剩余长度
        int n = a.length;

        if(n < 2){
            return;
        }

        //待排序的长度小于MIN_MERGE,直接采用插入排序完成
        if(n < MIN_MERGE){
            insertSort(a, 0, 0, a.length-1);
            return;
        }

        int base = 0;
        while(n > 0){
            int len = maxAscendingLen(a, base);
            if(len < MIN_MERGE){
                int abscent = n > MIN_MERGE ?  MIN_MERGE - len : n - len;
                insertSort(a, base, base + len-1, abscent);
                len = len + abscent;
            }
            pushRun(base, len);
            n = n - len;
            base = base + len;

            int x;
            while((x  = needMerge()) >= 0 ){
                mergeAt(x);
            }
        }
        forceMerge();
    }

    public static void main(String[] args){

        //随机产生测试用例
        Random rnd = new Random(System.currentTimeMillis());
        boolean flag = true;
        while(flag){

            //首先产生一个全部有序的数组
            Integer[] arr1 = new Integer[1000];
            for(int i = 0; i < arr1.length; i++){
                arr1[i] = i;
            }

            //有序的基础上随机交换一些值
            for(int i = 0; i < (int)(0.1*arr1.length); i++){
                int x,y,tmp;
                x = rnd.nextInt(arr1.length);
                y = rnd.nextInt(arr1.length);
                tmp = arr1[x];
                arr1[x] = arr1[y];
                arr1[y] = tmp;
            }

            //逆序部分数据
            for(int i = 0; i <(int)(0.05*arr1.length); i++){
                int x = rnd.nextInt(arr1.length);
                int y = rnd.nextInt((int)(arr1.length*0.01)+x);
                if(y >= arr1.length){
                    continue;
                }
                while(x < y){
                    int tmp;
                    tmp = arr1[x];
                    arr1[x] = arr1[y];
                    arr1[y] = tmp;
                    x++;
                    y--;
                }
            }

            Integer[] arr2 = arr1.clone();
            Integer[] arr3 = arr1.clone();
            Arrays.sort(arr2);

            SimpleTimSort<Integer> sts = new SimpleTimSort<Integer>(arr1);
            sts.timSort();

            //比较SimpleTimSort排序和库函数提供的排序结果比较是否一致
            //如果没有打印任何结果，说明排序结果正确
            if(!Arrays.deepEquals(arr1, arr2)){
                for(int i = 0; i < arr1.length; i++){
                    if(!arr1[i].equals(arr2[i])){
                        System.out.printf("%d: arr1 %d  arr2 %d\n",i,arr1[i],arr2[i]);
                    }
                }
                System.out.println(Arrays.deepToString(arr3));
                flag = false;
            }
        }
    }
}

3. Issues that should be paid attention to with the TimSort algorithm

The TimSort algorithm will only merge two consecutive fragments, so as to ensure the stability of the algorithm.

There is a certain relationship between the minimum merge length and the length of the stack. If the minimum merge length is increased, the length of the stack should also be increased, otherwise it may cause the risk of the stack going out of bounds (the stack in the code is implemented by an array of length 40 of).

4. The full version of the TimSort algorithm

In fact, the full version of the TimSort algorithm will have a lot of optimizations on the above-mentioned simple TimSort algorithm. For example, when the ordered sequence is smaller than the minimum merge length, we can use a method similar to binary search to find the position where it should be inserted to extend the length of the array. Another example is that in the galloping mode, binary search is used to find the position of the first element of the second sequence in the first sequence. At the same time, a smaller auxiliary space can be used to complete the merge. Interested students can view the source code in Java Come and learn.
